What is the outside diameter of 1/2-inch pipe?

1/2-inch pipe measures 0.840 inches — 21.3 mm — across the outside, and that figure does not change with the schedule. The schedule sets the wall inside that fixed outside diameter, so the bore moves and the outside does not: schedule 40 is 0.109 in thick and leaves a 0.622 in bore, schedule 80 is 0.147 in and leaves 0.546 in. Dimensions from ASME B36.10M-2015.

What is the outside diameter of 3/4-inch pipe?

3/4-inch pipe measures 1.050 inches — 26.7 mm — across the outside, and that figure does not change with the schedule. The schedule sets the wall inside that fixed outside diameter, so the bore moves and the outside does not: schedule 40 is 0.113 in thick and leaves a 0.824 in bore, schedule 80 is 0.154 in and leaves 0.742 in. Dimensions from ASME B36.10M-2015.

What is the outside diameter of 1-inch pipe?

1-inch pipe measures 1.315 inches — 33.4 mm — across the outside, and that figure does not change with the schedule. The schedule sets the wall inside that fixed outside diameter, so the bore moves and the outside does not: schedule 40 is 0.133 in thick and leaves a 1.049 in bore, schedule 80 is 0.179 in and leaves 0.957 in. Dimensions from ASME B36.10M-2015.

What is the outside diameter of 1-1/2-inch pipe?

1-1/2-inch pipe measures 1.900 inches — 48.3 mm — across the outside, and that figure does not change with the schedule. The schedule sets the wall inside that fixed outside diameter, so the bore moves and the outside does not: schedule 40 is 0.145 in thick and leaves a 1.610 in bore, schedule 80 is 0.200 in and leaves 1.500 in. Dimensions from ASME B36.10M-2015.

What is the outside diameter of 2-inch pipe?

2-inch pipe measures 2.375 inches — 60.3 mm — across the outside, and that figure does not change with the schedule. The schedule sets the wall inside that fixed outside diameter, so the bore moves and the outside does not: schedule 40 is 0.154 in thick and leaves a 2.067 in bore, schedule 80 is 0.218 in and leaves 1.939 in. Dimensions from ASME B36.10M-2015.

What is the outside diameter of 3-inch pipe?

3-inch pipe measures 3.500 inches — 88.9 mm — across the outside, and that figure does not change with the schedule. The schedule sets the wall inside that fixed outside diameter, so the bore moves and the outside does not: schedule 40 is 0.216 in thick and leaves a 3.068 in bore, schedule 80 is 0.300 in and leaves 2.900 in. Dimensions from ASME B36.10M-2015.

What is the outside diameter of 4-inch pipe?

4-inch pipe measures 4.500 inches — 114.3 mm — across the outside, and that figure does not change with the schedule. The schedule sets the wall inside that fixed outside diameter, so the bore moves and the outside does not: schedule 40 is 0.237 in thick and leaves a 4.026 in bore, schedule 80 is 0.337 in and leaves 3.826 in. Dimensions from ASME B36.10M-2015.

What is the outside diameter of 6-inch pipe?

6-inch pipe measures 6.625 inches — 168.3 mm — across the outside, and that figure does not change with the schedule. The schedule sets the wall inside that fixed outside diameter, so the bore moves and the outside does not: schedule 40 is 0.280 in thick and leaves a 6.065 in bore, schedule 80 is 0.432 in and leaves 5.761 in. Dimensions from ASME B36.10M-2015.

What is the outside diameter of 8-inch pipe?

8-inch pipe measures 8.625 inches — 219.1 mm — across the outside, and that figure does not change with the schedule. The schedule sets the wall inside that fixed outside diameter, so the bore moves and the outside does not: schedule 40 is 0.322 in thick and leaves a 7.981 in bore, schedule 80 is 0.500 in and leaves 7.625 in. Dimensions from ASME B36.10M-2015.

What is the outside diameter of 10-inch pipe?

10-inch pipe measures 10.750 inches — 273 mm — across the outside, and that figure does not change with the schedule. The schedule sets the wall inside that fixed outside diameter, so the bore moves and the outside does not: schedule 40 is 0.365 in thick and leaves a 10.020 in bore, schedule 80 is 0.594 in and leaves 9.562 in. Dimensions from ASME B36.10M-2015.

What is the outside diameter of 12-inch pipe?

12-inch pipe measures 12.750 inches — 323.8 mm — across the outside, and that figure does not change with the schedule. The schedule sets the wall inside that fixed outside diameter, so the bore moves and the outside does not: schedule 40 is 0.406 in thick and leaves a 11.938 in bore, schedule 80 is 0.688 in and leaves 11.374 in. Dimensions from ASME B36.10M-2015.

Why isn't 2-inch pipe 2 inches?

Nominal pipe size is a trade designation, not a measurement. It originally approximated the bore of the pipe. Wall thicknesses changed over time, the outside diameter was standardised, and the name stayed. From NPS 14 upward the nominal size does equal the outside diameter in inches.

What does schedule mean on a pipe?

Schedule specifies wall thickness, not diameter. For any given nominal size, every schedule shares the same outside diameter; a higher schedule number means a thicker wall and therefore a smaller bore.

Is schedule 40 the same as STD?

Only through NPS 10. From NPS 12 upward they diverge: STD is fixed at 0.375 inches while schedule 40 keeps increasing. At NPS 24, schedule 40 is 0.688 inches and STD is still 0.375 inches.

What is the difference between NPS and DN?

They name the same physical pipe in different units. Above DN 100 the relationship is arithmetic — DN equals 25 times NPS. Below DN 100 it is an irregular lookup that no formula reproduces.

Does PVC use the same sizes as steel pipe?

PVC schedule 40 and 80 use exactly the same outside diameters as steel, across all 19 comparable sizes. The wall thicknesses are also the same numbers, but they mean different things: ASTM publishes a minimum wall for PVC, while ASME publishes a nominal wall for steel.

What are the standard pipe sizes?

Nominal pipe sizes run from NPS 1/8 to NPS 80 — 44 sizes in ASME B36.10M-2015 — and each one fixes an outside diameter that every schedule shares. The full series, with the schedule walls available at each size, is the chart on this page.

What are the standard tube sizes?

Tube has no nominal series: it is ordered by its exact outside diameter, so 'tube sizes' are simply the manufactured diameter range rather than a standard table. Pipe is the opposite — a nominal name over a fixed outside diameter — which is why a 2-inch pipe measures 2.375 inches across. This site covers pipe dimensions; tube sizing works to different standards entirely.

Pipe
Size Chart

The number on a pipe isn’t its size. Find what it actually measures.

The full chart

Every size and schedule in ASME B36.10M-2015 — 766 rows. Most charts online show 16. Tap any row for its full spec.

Showing 766 of 766 rows

Pipe dimensions to ASME B36.10M-2015 — 766 size and schedule combinations, nominal ⅛ in to 80 in.
NPS	DN	Schedule	OD		Wall		ID		Mass		In your country
NPS	DN	Schedule	in	mm	in	mm	in	mm	lb/ft	kg/m	OD mm	vs ASME
⅛	6	SCH 10	0.405	10.30	0.049	1.24	0.307	7.82	0.19	0.28
⅛	6	SCH 30	0.405	10.30	0.057	1.45	0.291	7.40	0.21	0.32
⅛	6	SCH 40 · STD	0.405	10.30	0.068	1.73	0.269	6.84	0.24	0.37
⅛	6	SCH 80 · XS	0.405	10.30	0.095	2.41	0.215	5.48	0.32	0.47
¼	8	SCH 10	0.540	13.70	0.065	1.65	0.410	10.40	0.33	0.49
¼	8	SCH 30	0.540	13.70	0.073	1.85	0.394	10.00	0.36	0.54
¼	8	SCH 40 · STD	0.540	13.70	0.088	2.24	0.364	9.22	0.42	0.63
¼	8	SCH 80 · XS	0.540	13.70	0.119	3.02	0.302	7.66	0.54	0.80
⅜	10	SCH 10	0.675	17.10	0.065	1.65	0.545	13.80	0.42	0.63
⅜	10	SCH 30	0.675	17.10	0.073	1.85	0.529	13.40	0.47	0.70
⅜	10	SCH 40 · STD	0.675	17.10	0.091	2.31	0.493	12.48	0.57	0.84
⅜	10	SCH 80 · XS	0.675	17.10	0.126	3.20	0.423	10.70	0.74	1.10
½	15	SCH 5	0.840	21.30	0.065	1.65	0.710	18.00	0.54	0.80
½	15	SCH 10	0.840	21.30	0.083	2.11	0.674	17.08	0.67	1.00
½	15	SCH 30	0.840	21.30	0.095	2.41	0.650	16.48	0.76	1.12
½	15	SCH 40 · STD	0.840	21.30	0.109	2.77	0.622	15.76	0.85	1.27
½	15	SCH 80 · XS	0.840	21.30	0.147	3.73	0.546	13.84	1.09	1.62
½	15	SCH 160	0.840	21.30	0.188	4.78	0.464	11.74	1.31	1.95
½	15	XXS	0.840	21.30	0.294	7.47	0.252	6.36	1.72	2.55
¾	20	SCH 5	1.050	26.70	0.065	1.65	0.920	23.40	0.68	1.02
¾	20	SCH 10	1.050	26.70	0.083	2.11	0.884	22.48	0.86	1.28
¾	20	SCH 30	1.050	26.70	0.095	2.41	0.860	21.88	0.97	1.44
¾	20	SCH 40 · STD	1.050	26.70	0.113	2.87	0.824	20.96	1.13	1.69
¾	20	SCH 80 · XS	1.050	26.70	0.154	3.91	0.742	18.88	1.48	2.20
¾	20	SCH 160	1.050	26.70	0.219	5.56	0.612	15.58	1.95	2.90
¾	20	XXS	1.050	26.70	0.308	7.82	0.434	11.06	2.44	3.64
1	25	SCH 5	1.315	33.40	0.065	1.65	1.185	30.10	0.87	1.29
1	25	SCH 10	1.315	33.40	0.109	2.77	1.097	27.86	1.41	2.09
1	25	SCH 30	1.315	33.40	0.114	2.90	1.087	27.60	1.46	2.18
1	25	SCH 40 · STD	1.315	33.40	0.133	3.38	1.049	26.64	1.68	2.50
1	25	SCH 80 · XS	1.315	33.40	0.179	4.55	0.957	24.30	2.17	3.24
1	25	SCH 160	1.315	33.40	0.250	6.35	0.815	20.70	2.85	4.24
1	25	XXS	1.315	33.40	0.358	9.09	0.599	15.22	3.66	5.45
1 ¼	32	SCH 5	1.660	42.20	0.065	1.65	1.530	38.90	1.11	1.65
1 ¼	32	SCH 10	1.660	42.20	0.109	2.77	1.442	36.66	1.81	2.69
1 ¼	32	SCH 30	1.660	42.20	0.117	2.97	1.426	36.26	1.93	2.87
1 ¼	32	SCH 40 · STD	1.660	42.20	0.140	3.56	1.380	35.08	2.27	3.39
1 ¼	32	SCH 80 · XS	1.660	42.20	0.191	4.85	1.278	32.50	3.00	4.47
1 ¼	32	SCH 160	1.660	42.20	0.250	6.35	1.160	29.50	3.77	5.61
1 ¼	32	XXS	1.660	42.20	0.382	9.70	0.896	22.80	5.22	7.77
1 ½	40	SCH 5	1.900	48.30	0.065	1.65	1.770	45.00	1.27	1.90
1 ½	40	SCH 10	1.900	48.30	0.109	2.77	1.682	42.76	2.09	3.11
1 ½	40	SCH 30	1.900	48.30	0.125	3.18	1.650	41.94	2.37	3.54
1 ½	40	SCH 40 · STD	1.900	48.30	0.145	3.68	1.610	40.94	2.72	4.05
1 ½	40	SCH 80 · XS	1.900	48.30	0.200	5.08	1.500	38.14	3.63	5.41
1 ½	40	SCH 160	1.900	48.30	0.281	7.14	1.338	34.02	4.86	7.25
1 ½	40	XXS	1.900	48.30	0.400	10.15	1.100	28.00	6.41	9.55
2	50	SCH 5	2.375	60.30	0.065	1.65	2.245	57.00	1.60	2.39
2	50	—	2.375	60.30	0.083	2.11	2.209	56.08	2.03	3.03
2	50	SCH 10	2.375	60.30	0.109	2.77	2.157	54.76	2.64	3.93
2	50	SCH 30	2.375	60.30	0.125	3.18	2.125	53.94	3.01	4.48
2	50	—	2.375	60.30	0.141	3.58	2.093	53.14	3.37	5.01
2	50	SCH 40 · STD	2.375	60.30	0.154	3.91	2.067	52.48	3.66	5.44
2	50	—	2.375	60.30	0.172	4.37	2.031	51.56	4.05	6.03
2	50	—	2.375	60.30	0.188	4.78	1.999	50.74	4.39	6.54
2	50	SCH 80 · XS	2.375	60.30	0.218	5.54	1.939	49.22	5.03	7.48
2	50	—	2.375	60.30	0.250	6.35	1.875	47.60	5.68	8.45
2	50	—	2.375	60.30	0.281	7.14	1.813	46.02	6.29	9.36
2	50	SCH 160	2.375	60.30	0.344	8.74	1.687	42.82	7.47	11.11
2	50	XXS	2.375	60.30	0.436	11.07	1.503	38.16	9.04	13.44
2 ½	65	SCH 5	2.875	73.00	0.083	2.11	2.709	68.78	2.48	3.69
2 ½	65	—	2.875	73.00	0.109	2.77	2.657	67.46	3.22	4.80
2 ½	65	SCH 10	2.875	73.00	0.120	3.05	2.635	66.90	3.53	5.26
2 ½	65	—	2.875	73.00	0.125	3.18	2.625	66.64	3.67	5.47
2 ½	65	—	2.875	73.00	0.141	3.58	2.593	65.84	4.12	6.13
2 ½	65	—	2.875	73.00	0.156	3.96	2.563	65.08	4.53	6.74
2 ½	65	—	2.875	73.00	0.172	4.37	2.531	64.26	4.97	7.40
2 ½	65	SCH 30	2.875	73.00	0.188	4.78	2.499	63.44	5.40	8.04
2 ½	65	SCH 40 · STD	2.875	73.00	0.203	5.16	2.469	62.68	5.80	8.63
2 ½	65	—	2.875	73.00	0.216	5.49	2.443	62.02	6.14	9.14
2 ½	65	—	2.875	73.00	0.250	6.35	2.375	60.30	7.01	10.44
2 ½	65	SCH 80 · XS	2.875	73.00	0.276	7.01	2.323	58.98	7.67	11.41
2 ½	65	SCH 160	2.875	73.00	0.375	9.53	2.125	53.94	10.02	14.92
2 ½	65	XXS	2.875	73.00	0.552	14.02	1.771	44.96	13.71	20.39
3	80	SCH 5	3.500	88.90	0.083	2.11	3.334	84.68	3.03	4.52
3	80	—	3.500	88.90	0.109	2.77	3.282	83.36	3.95	5.88
3	80	SCH 10	3.500	88.90	0.120	3.05	3.260	82.80	4.34	6.46
3	80	—	3.500	88.90	0.125	3.18	3.250	82.54	4.51	6.72
3	80	—	3.500	88.90	0.141	3.58	3.218	81.74	5.06	7.53
3	80	—	3.500	88.90	0.156	3.96	3.188	80.98	5.58	8.29
3	80	—	3.500	88.90	0.172	4.37	3.156	80.16	6.12	9.11
3	80	SCH 30	3.500	88.90	0.188	4.78	3.124	79.34	6.66	9.92
3	80	SCH 40 · STD	3.500	88.90	0.216	5.49	3.068	77.92	7.58	11.29
3	80	—	3.500	88.90	0.250	6.35	3.000	76.20	8.69	12.93
3	80	—	3.500	88.90	0.281	7.14	2.938	74.62	9.67	14.40
3	80	SCH 80 · XS	3.500	88.90	0.300	7.62	2.900	73.66	10.26	15.27
3	80	SCH 160	3.500	88.90	0.438	11.13	2.624	66.64	14.34	21.34
3	80	XXS	3.500	88.90	0.600	15.24	2.300	58.42	18.60	27.68
3 ½	90	SCH 5	4.000	101.60	0.083	2.11	3.834	97.38	3.48	5.18
3 ½	90	—	4.000	101.60	0.109	2.77	3.782	96.06	4.53	6.75
3 ½	90	SCH 10	4.000	101.60	0.120	3.05	3.760	95.50	4.98	7.41
3 ½	90	—	4.000	101.60	0.125	3.18	3.750	95.24	5.18	7.72
3 ½	90	—	4.000	101.60	0.141	3.58	3.718	94.44	5.82	8.65
3 ½	90	—	4.000	101.60	0.156	3.96	3.688	93.68	6.41	9.54
3 ½	90	—	4.000	101.60	0.172	4.37	3.656	92.86	7.04	10.48
3 ½	90	SCH 30	4.000	101.60	0.188	4.78	3.624	92.04	7.66	11.41
3 ½	90	SCH 40 · STD	4.000	101.60	0.226	5.74	3.548	90.12	9.12	13.57
3 ½	90	—	4.000	101.60	0.250	6.35	3.500	88.90	10.02	14.91
3 ½	90	—	4.000	101.60	0.281	7.14	3.438	87.32	11.17	16.63
3 ½	90	SCH 80 · XS	4.000	101.60	0.318	8.08	3.364	85.44	12.52	18.63
4	100	SCH 5	4.500	114.30	0.083	2.11	4.334	110.08	3.92	5.84
4	100	—	4.500	114.30	0.109	2.77	4.282	108.76	5.12	7.62
4	100	SCH 10	4.500	114.30	0.120	3.05	4.260	108.20	5.62	8.37
4	100	—	4.500	114.30	0.125	3.18	4.250	107.94	5.85	8.71
4	100	—	4.500	114.30	0.141	3.58	4.218	107.14	6.57	9.78
4	100	—	4.500	114.30	0.156	3.96	4.188	106.38	7.24	10.78
4	100	—	4.500	114.30	0.172	4.37	4.156	105.56	7.96	11.85
4	100	SCH 30	4.500	114.30	0.188	4.78	4.124	104.74	8.67	12.91
4	100	—	4.500	114.30	0.203	5.16	4.094	103.98	9.32	13.89
4	100	—	4.500	114.30	0.219	5.56	4.062	103.18	10.02	14.91
4	100	SCH 40 · STD	4.500	114.30	0.237	6.02	4.026	102.26	10.80	16.07
4	100	—	4.500	114.30	0.250	6.35	4.000	101.60	11.36	16.90
4	100	—	4.500	114.30	0.281	7.14	3.938	100.02	12.67	18.87
4	100	—	4.500	114.30	0.312	7.92	3.876	98.46	13.97	20.78
4	100	SCH 80 · XS	4.500	114.30	0.337	8.56	3.826	97.18	15.00	22.32
4	100	SCH 120	4.500	114.30	0.438	11.13	3.624	92.04	19.02	28.32
4	100	SCH 160	4.500	114.30	0.531	13.49	3.438	87.32	22.53	33.54
4	100	XXS	4.500	114.30	0.674	17.12	3.152	80.06	27.57	41.03
5	125	—	5.563	141.30	0.083	2.11	5.397	137.08	4.86	7.24
5	125	SCH 5	5.563	141.30	0.109	2.77	5.345	135.76	6.36	9.46
5	125	—	5.563	141.30	0.125	3.18	5.313	134.94	7.27	10.83
5	125	SCH 10	5.563	141.30	0.134	3.40	5.295	134.50	7.78	11.56
5	125	—	5.563	141.30	0.156	3.96	5.251	133.38	9.02	13.41
5	125	—	5.563	141.30	0.188	4.78	5.187	131.74	10.80	16.09
5	125	—	5.563	141.30	0.219	5.56	5.125	130.18	12.51	18.61
5	125	SCH 40 · STD	5.563	141.30	0.258	6.55	5.047	128.20	14.63	21.77
5	125	—	5.563	141.30	0.281	7.14	5.001	127.02	15.87	23.62
5	125	—	5.563	141.30	0.312	7.92	4.939	125.46	17.51	26.05
5	125	—	5.563	141.30	0.344	8.74	4.875	123.82	19.19	28.57
5	125	SCH 80 · XS	5.563	141.30	0.375	9.53	4.813	122.24	20.80	30.97
5	125	SCH 120	5.563	141.30	0.500	12.70	4.563	115.90	27.06	40.27
5	125	SCH 160	5.563	141.30	0.625	15.88	4.313	109.54	32.99	49.12
5	125	XXS	5.563	141.30	0.750	19.05	4.063	103.20	38.59	57.43
6	150	—	6.625	168.30	0.083	2.11	6.459	164.08	5.80	8.65
6	150	SCH 5	6.625	168.30	0.109	2.77	6.407	162.76	7.59	11.31
6	150	—	6.625	168.30	0.125	3.18	6.375	161.94	8.69	12.95
6	150	SCH 10	6.625	168.30	0.134	3.40	6.357	161.50	9.30	13.83
6	150	—	6.625	168.30	0.141	3.58	6.343	161.14	9.77	14.54
6	150	—	6.625	168.30	0.156	3.96	6.313	160.38	10.79	16.05
6	150	—	6.625	168.30	0.172	4.37	6.281	159.56	11.87	17.67
6	150	—	6.625	168.30	0.188	4.78	6.249	158.74	12.94	19.27
6	150	—	6.625	168.30	0.203	5.16	6.219	157.98	13.94	20.76
6	150	—	6.625	168.30	0.219	5.56	6.187	157.18	15.00	22.31
6	150	—	6.625	168.30	0.250	6.35	6.125	155.60	17.04	25.36
6	150	SCH 40 · STD	6.625	168.30	0.280	7.11	6.065	154.08	18.99	28.26
6	150	—	6.625	168.30	0.312	7.92	6.001	152.46	21.06	31.32
6	150	—	6.625	168.30	0.344	8.74	5.937	150.82	23.10	34.39
6	150	—	6.625	168.30	0.375	9.53	5.875	149.24	25.05	37.31
6	150	SCH 80 · XS	6.625	168.30	0.432	10.97	5.761	146.36	28.60	42.56
6	150	—	6.625	168.30	0.500	12.70	5.625	142.90	32.74	48.73
6	150	SCH 120	6.625	168.30	0.562	14.27	5.501	139.76	36.42	54.20
6	150	—	6.625	168.30	0.625	15.88	5.375	136.54	40.09	59.69
6	150	SCH 160	6.625	168.30	0.719	18.26	5.187	131.78	45.39	67.56
6	150	—	6.625	168.30	0.750	19.05	5.125	130.20	47.10	70.11
6	150	XXS	6.625	168.30	0.864	21.95	4.897	124.40	53.21	79.22
6	150	—	6.625	168.30	0.875	22.23	4.875	123.84	53.78	80.07
8	200	SCH 5	8.625	219.10	0.109	2.77	8.407	213.56	9.92	14.78
8	200	—	8.625	219.10	0.125	3.18	8.375	212.74	11.36	16.93
8	200	SCH 10	8.625	219.10	0.148	3.76	8.329	211.58	13.41	19.97
8	200	—	8.625	219.10	0.156	3.96	8.313	211.18	14.12	21.01
8	200	—	8.625	219.10	0.188	4.78	8.249	209.54	16.96	25.26
8	200	—	8.625	219.10	0.203	5.16	8.219	208.78	18.28	27.22
8	200	—	8.625	219.10	0.219	5.56	8.187	207.98	19.68	29.28
8	200	SCH 20	8.625	219.10	0.250	6.35	8.125	206.40	22.38	33.31
8	200	SCH 30	8.625	219.10	0.277	7.04	8.071	205.02	24.72	36.81
8	200	—	8.625	219.10	0.312	7.92	8.001	203.26	27.73	41.24
8	200	SCH 40 · STD	8.625	219.10	0.322	8.18	7.981	202.74	28.58	42.55
8	200	—	8.625	219.10	0.344	8.74	7.937	201.62	30.45	45.34
8	200	—	8.625	219.10	0.375	9.53	7.875	200.04	33.07	49.25
8	200	SCH 60	8.625	219.10	0.406	10.31	7.813	198.48	35.67	53.08
8	200	—	8.625	219.10	0.438	11.13	7.749	196.84	38.33	57.08
8	200	SCH 80 · XS	8.625	219.10	0.500	12.70	7.625	193.70	43.43	64.64
8	200	—	8.625	219.10	0.562	14.27	7.501	190.56	48.44	72.08
8	200	SCH 100	8.625	219.10	0.594	15.09	7.437	188.92	51.00	75.92
8	200	—	8.625	219.10	0.625	15.88	7.375	187.34	53.45	79.58
8	200	SCH 120	8.625	219.10	0.719	18.26	7.187	182.58	60.77	90.44
8	200	—	8.625	219.10	0.750	19.05	7.125	181.00	63.14	93.98
8	200	SCH 140	8.625	219.10	0.812	20.62	7.001	177.86	67.82	100.92
8	200	XXS	8.625	219.10	0.875	22.23	6.875	174.64	72.49	107.92
8	200	SCH 160	8.625	219.10	0.906	23.01	6.813	173.08	74.76	111.27
8	200	—	8.625	219.10	1.000	25.40	6.625	168.30	81.51	121.33
10	250	SCH 5	10.750	273.00	0.134	3.40	10.482	266.20	15.21	22.60
10	250	—	10.750	273.00	0.156	3.96	10.438	265.08	17.67	26.27
10	250	SCH 10	10.750	273.00	0.165	4.19	10.420	264.62	18.67	27.77
10	250	—	10.750	273.00	0.188	4.78	10.374	263.44	21.23	31.62
10	250	—	10.750	273.00	0.203	5.16	10.344	262.68	22.89	34.08
10	250	—	10.750	273.00	0.219	5.56	10.312	261.88	24.65	36.67
10	250	SCH 20	10.750	273.00	0.250	6.35	10.250	260.30	28.06	41.76
10	250	—	10.750	273.00	0.279	7.09	10.192	258.82	31.23	46.49
10	250	SCH 30	10.750	273.00	0.307	7.80	10.136	257.40	34.27	51.01
10	250	—	10.750	273.00	0.344	8.74	10.062	255.52	38.27	56.96
10	250	SCH 40 · STD	10.750	273.00	0.365	9.27	10.020	254.46	40.52	60.29
10	250	—	10.750	273.00	0.438	11.13	9.874	250.74	48.28	71.87
10	250	SCH 60 · XS	10.750	273.00	0.500	12.70	9.750	247.60	54.79	81.52
10	250	—	10.750	273.00	0.562	14.27	9.626	244.46	61.21	91.05
10	250	SCH 80	10.750	273.00	0.594	15.09	9.562	242.82	64.49	95.97
10	250	—	10.750	273.00	0.625	15.88	9.500	241.24	67.65	100.69
10	250	SCH 100	10.750	273.00	0.719	18.26	9.312	236.48	77.10	114.71
10	250	—	10.750	273.00	0.812	20.62	9.126	231.76	86.27	128.33
10	250	SCH 120	10.750	273.00	0.844	21.44	9.062	230.12	89.38	133.00
10	250	—	10.750	273.00	0.875	22.23	9.000	228.54	92.37	137.47
10	250	—	10.750	273.00	0.938	23.83	8.874	225.34	98.39	146.42
10	250	SCH 140 · XXS	10.750	273.00	1.000	25.40	8.750	222.20	104.23	155.09
10	250	SCH 160	10.750	273.00	1.125	28.58	8.500	215.84	115.75	172.26
10	250	—	10.750	273.00	1.250	31.75	8.250	209.50	126.94	188.89
12	300	SCH 5	12.750	323.80	0.156	3.96	12.438	315.88	21.00	31.23
12	300	—	12.750	323.80	0.172	4.37	12.406	315.06	23.13	34.42
12	300	SCH 10	12.750	323.80	0.180	4.57	12.390	314.66	24.19	35.98
12	300	—	12.750	323.80	0.188	4.78	12.374	314.24	25.25	37.60
12	300	—	12.750	323.80	0.203	5.16	12.344	313.48	27.23	40.55
12	300	—	12.750	323.80	0.219	5.56	12.312	312.68	29.34	43.63
12	300	SCH 20	12.750	323.80	0.250	6.35	12.250	311.10	33.41	49.71
12	300	—	12.750	323.80	0.281	7.14	12.188	309.52	37.46	55.76
12	300	—	12.750	323.80	0.312	7.92	12.126	307.96	41.48	61.69
12	300	SCH 30	12.750	323.80	0.330	8.38	12.090	307.04	43.81	65.18
12	300	—	12.750	323.80	0.344	8.74	12.062	306.32	45.62	67.90
12	300	STD	12.750	323.80	0.375	9.53	12.000	304.74	49.61	73.86
12	300	SCH 40	12.750	323.80	0.406	10.31	11.938	303.18	53.58	79.70
12	300	—	12.750	323.80	0.438	11.13	11.874	301.54	57.65	85.82
12	300	XS	12.750	323.80	0.500	12.70	11.750	298.40	65.48	97.43
12	300	SCH 60	12.750	323.80	0.562	14.27	11.626	295.26	73.22	108.92
12	300	—	12.750	323.80	0.625	15.88	11.500	292.04	81.01	120.58
12	300	SCH 80	12.750	323.80	0.688	17.48	11.374	288.84	88.71	132.04
12	300	—	12.750	323.80	0.750	19.05	11.250	285.70	96.21	143.16
12	300	—	12.750	323.80	0.812	20.62	11.126	282.56	103.63	154.16
12	300	SCH 100	12.750	323.80	0.844	21.44	11.062	280.92	107.42	159.86
12	300	—	12.750	323.80	0.875	22.23	11.000	279.34	111.08	165.32
12	300	—	12.750	323.80	0.938	23.83	10.874	276.14	118.44	176.28
12	300	SCH 120 · XXS	12.750	323.80	1.000	25.40	10.750	273.00	125.61	186.91
12	300	—	12.750	323.80	1.062	26.97	10.626	269.86	132.69	197.42
12	300	SCH 140	12.750	323.80	1.125	28.58	10.500	266.64	139.81	208.07
12	300	—	12.750	323.80	1.250	31.75	10.250	260.30	153.67	228.66
12	300	SCH 160	12.750	323.80	1.312	33.32	10.126	257.16	160.42	238.68
14	350	SCH 5	14.000	355.60	0.156	3.96	13.688	347.68	23.09	34.34
14	350	—	14.000	355.60	0.188	4.78	13.624	346.04	27.76	41.35
14	350	—	14.000	355.60	0.203	5.16	13.594	345.28	29.94	44.59
14	350	—	14.000	355.60	0.210	5.33	13.580	344.94	30.96	46.04
14	350	—	14.000	355.60	0.219	5.56	13.562	344.48	32.26	47.99
14	350	SCH 10	14.000	355.60	0.250	6.35	13.500	342.90	36.75	54.69
14	350	—	14.000	355.60	0.281	7.14	13.438	341.32	41.21	61.35
14	350	SCH 20	14.000	355.60	0.312	7.92	13.376	339.76	45.65	67.90
14	350	—	14.000	355.60	0.344	8.74	13.312	338.12	50.22	74.76
14	350	SCH 30 · STD	14.000	355.60	0.375	9.53	13.250	336.54	54.62	81.33
14	350	—	14.000	355.60	0.406	10.31	13.188	334.98	59.00	87.79
14	350	SCH 40	14.000	355.60	0.438	11.13	13.124	333.34	63.50	94.55
14	350	—	14.000	355.60	0.469	11.91	13.062	331.78	67.84	100.94
14	350	XS	14.000	355.60	0.500	12.70	13.000	330.20	72.16	107.39
14	350	—	14.000	355.60	0.562	14.27	12.876	327.06	80.73	120.11
14	350	SCH 60	14.000	355.60	0.594	15.09	12.812	325.42	85.13	126.71
14	350	—	14.000	355.60	0.625	15.88	12.750	323.84	89.36	133.03
14	350	—	14.000	355.60	0.688	17.48	12.624	320.64	97.91	145.75
14	350	SCH 80	14.000	355.60	0.750	19.05	12.500	317.50	106.23	158.10
14	350	—	14.000	355.60	0.812	20.62	12.376	314.36	114.48	170.33
14	350	—	14.000	355.60	0.875	22.23	12.250	311.14	122.77	182.75
14	350	SCH 100	14.000	355.60	0.938	23.83	12.124	307.94	130.98	194.96
14	350	—	14.000	355.60	1.000	25.40	12.000	304.80	138.97	206.82
14	350	—	14.000	355.60	1.062	26.97	11.876	301.66	146.88	218.56
14	350	SCH 120	14.000	355.60	1.094	27.79	11.812	300.02	150.93	224.65
14	350	—	14.000	355.60	1.125	28.58	11.750	298.44	154.84	230.48
14	350	SCH 140	14.000	355.60	1.250	31.75	11.500	292.10	170.37	253.56
14	350	SCH 160	14.000	355.60	1.406	35.71	11.188	284.18	189.29	281.70
14	350	—	14.000	355.60	2.000	50.80	10.000	254.00	256.56	381.83
14	350	—	14.000	355.60	2.125	53.98	9.750	247.64	269.75	401.50
14	350	—	14.000	355.60	2.200	55.88	9.600	243.84	277.51	413.01
14	350	—	14.000	355.60	2.500	63.50	9.000	228.60	307.34	457.40
16	400	SCH 5	16.000	406.40	0.165	4.19	15.670	398.02	27.93	41.56
16	400	—	16.000	406.40	0.188	4.78	15.624	396.84	31.78	47.34
16	400	—	16.000	406.40	0.203	5.16	15.594	396.08	34.28	51.06
16	400	—	16.000	406.40	0.219	5.56	15.562	395.28	36.95	54.96
16	400	SCH 10	16.000	406.40	0.250	6.35	15.500	393.70	42.09	62.64
16	400	—	16.000	406.40	0.281	7.14	15.438	392.12	47.22	70.30
16	400	SCH 20	16.000	406.40	0.312	7.92	15.376	390.56	52.32	77.83
16	400	—	16.000	406.40	0.344	8.74	15.312	388.92	57.57	85.71
16	400	SCH 30 · STD	16.000	406.40	0.375	9.53	15.250	387.34	62.64	93.27
16	400	—	16.000	406.40	0.406	10.31	15.188	385.78	67.68	100.70
16	400	—	16.000	406.40	0.438	11.13	15.124	384.14	72.86	108.49
16	400	—	16.000	406.40	0.469	11.91	15.062	382.58	77.87	115.86
16	400	SCH 40 · XS	16.000	406.40	0.500	12.70	15.000	381.00	82.85	123.30
16	400	—	16.000	406.40	0.562	14.27	14.876	377.86	92.75	137.99
16	400	—	16.000	406.40	0.625	15.88	14.750	374.64	102.72	152.93
16	400	SCH 60	16.000	406.40	0.656	16.66	14.688	373.08	107.60	160.12
16	400	—	16.000	406.40	0.688	17.48	14.624	371.44	112.61	167.65
16	400	—	16.000	406.40	0.750	19.05	14.500	368.30	122.27	181.97
16	400	—	16.000	406.40	0.812	20.62	14.376	365.16	131.84	196.16
16	400	SCH 80	16.000	406.40	0.844	21.44	14.312	363.52	136.74	203.53
16	400	—	16.000	406.40	0.875	22.23	14.250	361.94	141.47	210.60
16	400	—	16.000	406.40	0.938	23.83	14.124	358.74	151.03	224.82
16	400	—	16.000	406.40	1.000	25.40	14.000	355.60	160.35	238.65
16	400	SCH 100	16.000	406.40	1.031	26.19	13.938	354.02	164.98	245.56
16	400	—	16.000	406.40	1.062	26.97	13.876	352.46	169.59	252.35
16	400	—	16.000	406.40	1.125	28.58	13.750	349.24	178.89	266.28
16	400	—	16.000	406.40	1.188	30.18	13.624	346.04	188.11	280.00
16	400	SCH 120	16.000	406.40	1.219	30.96	13.562	344.48	192.61	286.64
16	400	—	16.000	406.40	1.250	31.75	13.500	342.90	197.10	293.33
16	400	SCH 140	16.000	406.40	1.438	36.53	13.124	333.34	223.85	333.19
16	400	SCH 160	16.000	406.40	1.594	40.49	12.812	325.42	245.48	365.36
18	450	SCH 5	18.000	457.00	0.165	4.19	17.670	448.62	31.46	46.79
18	450	—	18.000	457.00	0.188	4.78	17.624	447.44	35.80	53.30
18	450	—	18.000	457.00	0.219	5.56	17.562	445.88	41.63	61.90
18	450	SCH 10	18.000	457.00	0.250	6.35	17.500	444.30	47.44	70.57
18	450	—	18.000	457.00	0.281	7.14	17.438	442.72	53.23	79.21
18	450	SCH 20	18.000	457.00	0.312	7.92	17.376	441.16	58.99	87.71
18	450	—	18.000	457.00	0.344	8.74	17.312	439.52	64.93	96.61
18	450	STD	18.000	457.00	0.375	9.53	17.250	437.94	70.65	105.16
18	450	—	18.000	457.00	0.406	10.31	17.188	436.38	76.36	113.57
18	450	SCH 30	18.000	457.00	0.438	11.13	17.124	434.74	82.23	122.38
18	450	—	18.000	457.00	0.469	11.91	17.062	433.18	87.89	130.72
18	450	XS	18.000	457.00	0.500	12.70	17.000	431.60	93.54	139.15
18	450	SCH 40	18.000	457.00	0.562	14.27	16.876	428.46	104.76	155.80
18	450	—	18.000	457.00	0.625	15.88	16.750	425.24	116.09	172.74
18	450	—	18.000	457.00	0.688	17.48	16.624	422.04	127.33	189.46
18	450	SCH 60	18.000	457.00	0.750	19.05	16.500	418.90	138.30	205.74
18	450	—	18.000	457.00	0.812	20.62	16.376	415.76	149.20	221.90
18	450	—	18.000	457.00	0.875	22.23	16.250	412.54	160.18	238.34
18	450	SCH 80	18.000	457.00	0.938	23.83	16.124	409.34	171.08	254.55
18	450	—	18.000	457.00	1.000	25.40	16.000	406.20	181.73	270.34
18	450	—	18.000	457.00	1.062	26.97	15.876	403.06	192.29	286.00
18	450	—	18.000	457.00	1.125	28.58	15.750	399.84	202.94	301.94
18	450	SCH 100	18.000	457.00	1.156	29.36	15.688	398.28	208.15	309.62
18	450	—	18.000	457.00	1.188	30.18	15.624	396.64	213.51	317.66
18	450	—	18.000	457.00	1.250	31.75	15.500	393.50	223.82	332.95
18	450	SCH 120	18.000	457.00	1.375	34.93	15.250	387.14	244.37	363.56
18	450	SCH 140	18.000	457.00	1.562	39.67	14.876	377.66	274.48	408.26
18	450	SCH 160	18.000	457.00	1.781	45.24	14.438	366.52	308.79	459.37
20	500	SCH 5	20.000	508.00	0.188	4.78	19.624	498.44	39.82	59.32
20	500	—	20.000	508.00	0.219	5.56	19.562	496.88	46.31	68.89
20	500	SCH 10	20.000	508.00	0.250	6.35	19.500	495.30	52.78	78.55
20	500	—	20.000	508.00	0.281	7.14	19.438	493.72	59.23	88.19
20	500	—	20.000	508.00	0.312	7.92	19.376	492.16	65.67	97.67
20	500	—	20.000	508.00	0.344	8.74	19.312	490.52	72.28	107.61
20	500	SCH 20 · STD	20.000	508.00	0.375	9.53	19.250	488.94	78.67	117.14
20	500	—	20.000	508.00	0.406	10.31	19.188	487.38	85.04	126.53
20	500	—	20.000	508.00	0.438	11.13	19.124	485.74	91.59	136.37
20	500	—	20.000	508.00	0.469	11.91	19.062	484.18	97.92	145.70
20	500	SCH 30 · XS	20.000	508.00	0.500	12.70	19.000	482.60	104.23	155.12
20	500	—	20.000	508.00	0.562	14.27	18.876	479.46	116.78	173.74
20	500	SCH 40	20.000	508.00	0.594	15.09	18.812	477.82	123.22	183.42
20	500	—	20.000	508.00	0.625	15.88	18.750	476.24	129.45	192.72
20	500	—	20.000	508.00	0.688	17.48	18.624	473.04	142.03	211.44
20	500	—	20.000	508.00	0.750	19.05	18.500	469.90	154.34	229.70
20	500	SCH 60	20.000	508.00	0.812	20.62	18.376	466.76	166.56	247.83
20	500	—	20.000	508.00	0.875	22.23	18.250	463.54	178.89	266.30
20	500	—	20.000	508.00	0.938	23.83	18.124	460.34	191.14	284.52
20	500	—	20.000	508.00	1.000	25.40	18.000	457.20	203.11	302.28
20	500	SCH 80	20.000	508.00	1.031	26.19	17.938	455.62	209.06	311.18
20	500	—	20.000	508.00	1.062	26.97	17.876	454.06	215.00	319.92
20	500	—	20.000	508.00	1.125	28.58	17.750	450.84	227.00	337.89
20	500	—	20.000	508.00	1.188	30.18	17.624	447.64	238.91	355.61
20	500	—	20.000	508.00	1.250	31.75	17.500	444.50	250.55	372.88
20	500	SCH 100	20.000	508.00	1.281	32.54	17.438	442.92	256.34	381.53
20	500	—	20.000	508.00	1.312	33.32	17.376	441.36	262.10	390.03
20	500	—	20.000	508.00	1.375	34.93	17.250	438.14	273.76	407.49
20	500	SCH 120	20.000	508.00	1.500	38.10	17.000	431.80	296.65	441.49
20	500	SCH 140	20.000	508.00	1.750	44.45	16.500	419.10	341.41	508.11
20	500	SCH 160	20.000	508.00	1.969	50.01	16.062	407.98	379.53	564.82
22	550	SCH 5	22.000	559.00	0.188	4.78	21.624	549.44	43.84	65.33
22	550	—	22.000	559.00	0.219	5.56	21.562	547.88	50.99	75.88
22	550	SCH 10	22.000	559.00	0.250	6.35	21.500	546.30	58.13	86.54
22	550	—	22.000	559.00	0.281	7.14	21.438	544.72	65.24	97.17
22	550	—	22.000	559.00	0.312	7.92	21.376	543.16	72.34	107.63
22	550	—	22.000	559.00	0.344	8.74	21.312	541.52	79.64	118.60
22	550	SCH 20 · STD	22.000	559.00	0.375	9.53	21.250	539.94	86.69	129.13
22	550	—	22.000	559.00	0.406	10.31	21.188	538.38	93.72	139.50
22	550	—	22.000	559.00	0.438	11.13	21.124	536.74	100.96	150.37
22	550	—	22.000	559.00	0.469	11.91	21.062	535.18	107.95	160.68
22	550	SCH 30 · XS	22.000	559.00	0.500	12.70	21.000	533.60	114.92	171.09
22	550	—	22.000	559.00	0.562	14.27	20.876	530.46	128.79	191.69
22	550	—	22.000	559.00	0.625	15.88	20.750	527.24	142.81	212.69
22	550	—	22.000	559.00	0.688	17.48	20.624	524.04	156.74	233.43
22	550	—	22.000	559.00	0.750	19.05	20.500	520.90	170.37	253.65
22	550	—	22.000	559.00	0.812	20.62	20.376	517.76	183.92	273.76
22	550	SCH 60	22.000	559.00	0.875	22.23	20.250	514.54	197.60	294.25
22	550	—	22.000	559.00	0.938	23.83	20.124	511.34	211.19	314.49
22	550	—	22.000	559.00	1.000	25.40	20.000	508.20	224.49	334.23
22	550	—	22.000	559.00	1.062	26.97	19.876	505.06	237.71	353.84
22	550	SCH 80	22.000	559.00	1.125	28.58	19.750	501.84	251.05	373.83
22	550	—	22.000	559.00	1.188	30.18	19.624	498.64	264.31	393.57
22	550	—	22.000	559.00	1.250	31.75	19.500	495.50	277.27	412.81
22	550	—	22.000	559.00	1.312	33.32	19.376	492.36	290.15	431.94
22	550	SCH 100	22.000	559.00	1.375	34.93	19.250	489.14	303.16	451.42
22	550	—	22.000	559.00	1.438	36.53	19.124	485.94	316.08	470.66
22	550	—	22.000	559.00	1.500	38.10	19.000	482.80	328.72	489.41
22	550	SCH 120	22.000	559.00	1.625	41.28	18.750	476.44	353.94	527.02
22	550	SCH 140	22.000	559.00	1.875	47.63	18.250	463.74	403.38	600.63
22	550	SCH 160	22.000	559.00	2.125	53.98	17.750	451.04	451.49	672.26
24	600	SCH 5	24.000	610.00	0.218	5.54	23.564	598.92	55.42	82.58
24	600	SCH 10	24.000	610.00	0.250	6.35	23.500	597.30	63.47	94.53
24	600	—	24.000	610.00	0.281	7.14	23.438	595.72	71.25	106.15
24	600	—	24.000	610.00	0.312	7.92	23.376	594.16	79.01	117.59
24	600	—	24.000	610.00	0.344	8.74	23.312	592.52	86.99	129.59
24	600	SCH 20 · STD	24.000	610.00	0.375	9.53	23.250	590.94	94.71	141.12
24	600	—	24.000	610.00	0.406	10.31	23.188	589.38	102.40	152.47
24	600	—	24.000	610.00	0.438	11.13	23.124	587.74	110.32	164.37
24	600	—	24.000	610.00	0.469	11.91	23.062	586.18	117.97	175.66
24	600	XS	24.000	610.00	0.500	12.70	23.000	584.60	125.61	187.06
24	600	SCH 30	24.000	610.00	0.562	14.27	22.876	581.46	140.81	209.64
24	600	—	24.000	610.00	0.625	15.88	22.750	578.24	156.17	232.66
24	600	SCH 40	24.000	610.00	0.688	17.48	22.624	575.04	171.45	255.41
24	600	—	24.000	610.00	0.750	19.05	22.500	571.90	186.41	277.61
24	600	—	24.000	610.00	0.812	20.62	22.376	568.76	201.28	299.69
24	600	—	24.000	610.00	0.875	22.23	22.250	565.54	216.31	322.21
24	600	—	24.000	610.00	0.938	23.83	22.124	562.34	231.25	344.46
24	600	SCH 60	24.000	610.00	0.969	24.61	22.062	560.78	238.57	355.26
24	600	—	24.000	610.00	1.000	25.40	22.000	559.20	245.87	366.17
24	600	—	24.000	610.00	1.062	26.97	21.876	556.06	260.41	387.76
24	600	—	24.000	610.00	1.125	28.58	21.750	552.84	275.10	409.77
24	600	—	24.000	610.00	1.188	30.18	21.624	549.64	289.71	431.52
24	600	SCH 80	24.000	610.00	1.219	30.96	21.562	548.08	296.86	442.08
24	600	—	24.000	610.00	1.250	31.75	21.500	546.50	304.00	452.74
24	600	—	24.000	610.00	1.312	33.32	21.376	543.36	318.21	473.84
24	600	—	24.000	610.00	1.375	34.93	21.250	540.14	332.56	495.35
24	600	—	24.000	610.00	1.438	36.53	21.124	536.94	346.83	516.60
24	600	—	24.000	610.00	1.500	38.10	21.000	533.80	360.79	537.33
24	600	SCH 100	24.000	610.00	1.531	38.89	20.938	532.22	367.74	547.71
24	600	—	24.000	610.00	1.562	39.67	20.876	530.66	374.67	557.93
24	600	SCH 120	24.000	610.00	1.812	46.02	20.376	517.96	429.79	640.03
24	600	SCH 140	24.000	610.00	2.062	52.37	19.876	505.26	483.57	720.15
24	600	SCH 160	24.000	610.00	2.344	59.54	19.312	490.92	542.64	808.22
26	650	—	26.000	660.00	0.250	6.35	25.500	647.30	68.82	102.36
26	650	—	26.000	660.00	0.281	7.14	25.438	645.72	77.26	114.95
26	650	SCH 10	26.000	660.00	0.312	7.92	25.376	644.16	85.68	127.36
26	650	—	26.000	660.00	0.344	8.74	25.312	642.52	94.35	140.37
26	650	STD	26.000	660.00	0.375	9.53	25.250	640.94	102.72	152.87
26	650	—	26.000	660.00	0.406	10.31	25.188	639.38	111.08	165.18
26	650	—	26.000	660.00	0.438	11.13	25.124	637.74	119.69	178.09
26	650	—	26.000	660.00	0.469	11.91	25.062	636.18	128.00	190.34
26	650	SCH 20 · XS	26.000	660.00	0.500	12.70	25.000	634.60	136.30	202.72
26	650	—	26.000	660.00	0.562	14.27	24.876	631.46	152.83	227.23
26	650	—	26.000	660.00	0.625	15.88	24.750	628.24	169.54	252.24
26	650	—	26.000	660.00	0.688	17.48	24.624	625.04	186.16	276.96
26	650	—	26.000	660.00	0.750	19.05	24.500	621.90	202.44	301.10
26	650	—	26.000	660.00	0.812	20.62	24.376	618.76	218.64	325.12
26	650	—	26.000	660.00	0.875	22.23	24.250	615.54	235.01	349.62
26	650	—	26.000	660.00	0.938	23.83	24.124	612.34	251.30	373.84
26	650	—	26.000	660.00	1.000	25.40	24.000	609.20	267.25	397.49
28	700	—	28.000	711.00	0.250	6.35	27.500	698.30	74.16	110.34
28	700	—	28.000	711.00	0.281	7.14	27.438	696.72	83.27	123.93
28	700	SCH 10	28.000	711.00	0.312	7.92	27.376	695.16	92.35	137.32
28	700	—	28.000	711.00	0.344	8.74	27.312	693.52	101.70	151.36
28	700	STD	28.000	711.00	0.375	9.53	27.250	691.94	110.74	164.85
28	700	—	28.000	711.00	0.406	10.31	27.188	690.38	119.76	178.15
28	700	—	28.000	711.00	0.438	11.13	27.124	688.74	129.05	192.09
28	700	—	28.000	711.00	0.469	11.91	27.062	687.18	138.03	205.32
28	700	SCH 20 · XS	28.000	711.00	0.500	12.70	27.000	685.60	146.99	218.69
28	700	—	28.000	711.00	0.562	14.27	26.876	682.46	164.84	245.18
28	700	SCH 30	28.000	711.00	0.625	15.88	26.750	679.24	182.90	272.21
28	700	—	28.000	711.00	0.688	17.48	26.624	676.04	200.87	298.95
28	700	—	28.000	711.00	0.750	19.05	26.500	672.90	218.48	325.06
28	700	—	28.000	711.00	0.812	20.62	26.376	669.76	236.00	351.05
28	700	—	28.000	711.00	0.875	22.23	26.250	666.54	253.72	377.58
28	700	—	28.000	711.00	0.938	23.83	26.124	663.34	271.36	403.81
28	700	—	28.000	711.00	1.000	25.40	26.000	660.20	288.63	429.44
30	750	SCH 5	30.000	762.00	0.250	6.35	29.500	749.30	79.51	118.33
30	750	—	30.000	762.00	0.281	7.14	29.438	747.72	89.27	132.91
30	750	SCH 10	30.000	762.00	0.312	7.92	29.376	746.16	99.02	147.28
30	750	—	30.000	762.00	0.344	8.74	29.312	744.52	109.06	162.35
30	750	STD	30.000	762.00	0.375	9.53	29.250	742.94	118.76	176.84
30	750	—	30.000	762.00	0.406	10.31	29.188	741.38	128.44	191.11
30	750	—	30.000	762.00	0.438	11.13	29.124	739.74	138.42	206.09
30	750	—	30.000	762.00	0.469	11.91	29.062	738.18	148.06	220.30
30	750	SCH 20 · XS	30.000	762.00	0.500	12.70	29.000	736.60	157.68	234.67
30	750	—	30.000	762.00	0.562	14.27	28.876	733.46	176.86	263.13
30	750	SCH 30	30.000	762.00	0.625	15.88	28.750	730.24	196.26	292.18
30	750	—	30.000	762.00	0.688	17.48	28.624	727.04	215.58	320.93
30	750	—	30.000	762.00	0.750	19.05	28.500	723.90	234.51	349.02
30	750	—	30.000	762.00	0.812	20.62	28.376	720.76	253.36	376.98
30	750	—	30.000	762.00	0.875	22.23	28.250	717.54	272.43	405.54
30	750	—	30.000	762.00	0.938	23.83	28.124	714.34	291.41	433.78
30	750	—	30.000	762.00	1.000	25.40	28.000	711.20	310.01	461.38
30	750	—	30.000	762.00	1.062	26.97	27.876	708.06	328.53	488.85
30	750	—	30.000	762.00	1.125	28.58	27.750	704.84	347.26	516.90
30	750	—	30.000	762.00	1.188	30.18	27.624	701.64	365.90	544.65
30	750	—	30.000	762.00	1.250	31.75	27.500	698.50	384.17	571.75
32	800	—	32.000	813.00	0.250	6.35	31.500	800.30	84.85	126.31
32	800	—	32.000	813.00	0.281	7.14	31.438	798.72	95.28	141.89
32	800	SCH 10	32.000	813.00	0.312	7.92	31.376	797.16	105.69	157.24
32	800	—	32.000	813.00	0.344	8.74	31.312	795.52	116.41	173.34
32	800	STD	32.000	813.00	0.375	9.53	31.250	793.94	126.78	188.82
32	800	—	32.000	813.00	0.406	10.31	31.188	792.38	137.12	204.08
32	800	—	32.000	813.00	0.438	11.13	31.124	790.74	147.78	220.09
32	800	—	32.000	813.00	0.469	11.91	31.062	789.18	158.08	235.28
32	800	SCH 20 · XS	32.000	813.00	0.500	12.70	31.000	787.60	168.37	250.64
32	800	—	32.000	813.00	0.562	14.27	30.876	784.46	188.87	281.07
32	800	SCH 30	32.000	813.00	0.625	15.88	30.750	781.24	209.62	312.15
32	800	SCH 40	32.000	813.00	0.688	17.48	30.624	778.04	230.29	342.91
32	800	—	32.000	813.00	0.750	19.05	30.500	774.90	250.55	372.98
32	800	—	32.000	813.00	0.812	20.62	30.376	771.76	270.72	402.92
32	800	—	32.000	813.00	0.875	22.23	30.250	768.54	291.13	433.49
32	800	—	32.000	813.00	0.938	23.83	30.124	765.34	311.47	463.75
32	800	—	32.000	813.00	1.000	25.40	30.000	762.20	331.39	493.32
32	800	—	32.000	813.00	1.062	26.97	29.876	759.06	351.23	522.77
32	800	—	32.000	813.00	1.125	28.58	29.750	755.84	371.31	552.85
32	800	—	32.000	813.00	1.188	30.18	29.624	752.64	391.30	582.61
32	800	—	32.000	813.00	1.250	31.75	29.500	749.50	410.90	611.68
34	850	—	34.000	864.00	0.250	6.35	33.500	851.30	90.20	134.30
34	850	—	34.000	864.00	0.281	7.14	33.438	849.72	101.29	150.87
34	850	SCH 10	34.000	864.00	0.312	7.92	33.376	848.16	112.36	167.20
34	850	—	34.000	864.00	0.344	8.74	33.312	846.52	123.77	184.33
34	850	STD	34.000	864.00	0.375	9.53	33.250	844.94	134.79	200.81
34	850	—	34.000	864.00	0.406	10.31	33.188	843.38	145.80	217.05
34	850	—	34.000	864.00	0.438	11.13	33.124	841.74	157.15	234.08
34	850	—	34.000	864.00	0.469	11.91	33.062	840.18	168.11	250.26
34	850	SCH 20 · XS	34.000	864.00	0.500	12.70	33.000	838.60	179.06	266.61
34	850	—	34.000	864.00	0.562	14.27	32.876	835.46	200.89	299.02
34	850	SCH 30	34.000	864.00	0.625	15.88	32.750	832.24	222.99	332.12
34	850	SCH 40	34.000	864.00	0.688	17.48	32.624	829.04	245.00	364.90
34	850	—	34.000	864.00	0.750	19.05	32.500	825.90	266.58	396.94
34	850	—	34.000	864.00	0.812	20.62	32.376	822.76	288.08	428.85
34	850	—	34.000	864.00	0.875	22.23	32.250	819.54	309.84	461.45
34	850	—	34.000	864.00	0.938	23.83	32.124	816.34	331.52	493.72
34	850	—	34.000	864.00	1.000	25.40	32.000	813.20	352.77	525.27
34	850	—	34.000	864.00	1.062	26.97	31.876	810.06	373.94	556.69
34	850	—	34.000	864.00	1.125	28.58	31.750	806.84	395.36	588.79
34	850	—	34.000	864.00	1.188	30.18	31.624	803.64	416.70	620.56
34	850	—	34.000	864.00	1.250	31.75	31.500	800.50	437.62	651.61
36	900	—	36.000	914.00	0.250	6.35	35.500	901.30	95.54	142.13
36	900	—	36.000	914.00	0.281	7.14	35.438	899.72	107.30	159.67
36	900	SCH 10	36.000	914.00	0.312	7.92	35.376	898.16	119.03	176.96
36	900	—	36.000	914.00	0.344	8.74	35.312	896.52	131.12	195.11
36	900	STD	36.000	914.00	0.375	9.53	35.250	894.94	142.81	212.56
36	900	—	36.000	914.00	0.406	10.31	35.188	893.38	154.48	229.76
36	900	—	36.000	914.00	0.438	11.13	35.124	891.74	166.51	247.81
36	900	—	36.000	914.00	0.469	11.91	35.062	890.18	178.14	264.94
36	900	SCH 20 · XS	36.000	914.00	0.500	12.70	35.000	888.60	189.75	282.27
36	900	—	36.000	914.00	0.562	14.27	34.876	885.46	212.90	316.61
36	900	SCH 30	36.000	914.00	0.625	15.88	34.750	882.24	236.35	351.70
36	900	—	36.000	914.00	0.688	17.48	34.624	879.04	259.71	386.45
36	900	SCH 40	36.000	914.00	0.750	19.05	34.500	875.90	282.62	420.42
36	900	—	36.000	914.00	0.812	20.62	34.376	872.76	305.44	454.27
36	900	—	36.000	914.00	0.875	22.23	34.250	869.54	328.55	488.86
36	900	—	36.000	914.00	0.938	23.83	34.124	866.34	351.57	523.11
36	900	—	36.000	914.00	1.000	25.40	34.000	863.20	374.15	556.59
36	900	—	36.000	914.00	1.062	26.97	33.876	860.06	396.64	589.95
36	900	—	36.000	914.00	1.125	28.58	33.750	856.84	419.42	624.03
36	900	—	36.000	914.00	1.188	30.18	33.624	853.64	442.10	657.77
36	900	—	36.000	914.00	1.250	31.75	33.500	850.50	464.35	690.76
38	950	—	38.000	965.00	0.312	7.92	37.376	949.16	125.70	186.93
38	950	—	38.000	965.00	0.344	8.74	37.312	947.52	138.47	206.10
38	950	STD	38.000	965.00	0.375	9.53	37.250	945.94	150.83	224.54
38	950	—	38.000	965.00	0.406	10.31	37.188	944.38	163.16	242.72
38	950	—	38.000	965.00	0.438	11.13	37.124	942.74	175.87	261.81
38	950	—	38.000	965.00	0.469	11.91	37.062	941.18	188.17	279.92
38	950	XS	38.000	965.00	0.500	12.70	37.000	939.60	200.44	298.24
38	950	—	38.000	965.00	0.562	14.27	36.876	936.46	224.92	334.56
38	950	—	38.000	965.00	0.625	15.88	36.750	933.24	249.71	371.68
38	950	—	38.000	965.00	0.688	17.48	36.624	930.04	274.42	408.44
38	950	—	38.000	965.00	0.750	19.05	36.500	926.90	298.65	444.38
38	950	—	38.000	965.00	0.812	20.62	36.376	923.76	322.80	480.21
38	950	—	38.000	965.00	0.875	22.23	36.250	920.54	347.26	516.82
38	950	—	38.000	965.00	0.938	23.83	36.124	917.34	371.63	553.08
38	950	—	38.000	965.00	1.000	25.40	36.000	914.20	395.53	588.53
38	950	—	38.000	965.00	1.062	26.97	35.876	911.06	419.35	623.87
38	950	—	38.000	965.00	1.125	28.58	35.750	907.84	443.47	659.97
38	950	—	38.000	965.00	1.188	30.18	35.624	904.64	467.50	695.73
38	950	—	38.000	965.00	1.250	31.75	35.500	901.50	491.07	730.69
40	1000	—	40.000	1016.00	0.312	7.92	39.376	1000.16	132.37	196.88
40	1000	—	40.000	1016.00	0.344	8.74	39.312	998.52	145.83	217.09
40	1000	STD	40.000	1016.00	0.375	9.53	39.250	996.94	158.85	236.53
40	1000	—	40.000	1016.00	0.406	10.31	39.188	995.38	171.84	255.69
40	1000	—	40.000	1016.00	0.438	11.13	39.124	993.74	185.24	275.80
40	1000	—	40.000	1016.00	0.469	11.91	39.062	992.18	198.19	294.90
40	1000	XS	40.000	1016.00	0.500	12.70	39.000	990.60	211.13	314.22
40	1000	—	40.000	1016.00	0.562	14.27	38.876	987.46	236.94	352.51
40	1000	—	40.000	1016.00	0.625	15.88	38.750	984.24	263.07	391.65
40	1000	—	40.000	1016.00	0.688	17.48	38.624	981.04	289.13	430.42
40	1000	—	40.000	1016.00	0.750	19.05	38.500	977.90	314.69	468.34
40	1000	—	40.000	1016.00	0.812	20.62	38.376	974.76	340.16	506.14
40	1000	—	40.000	1016.00	0.875	22.23	38.250	971.54	365.96	544.78
40	1000	—	40.000	1016.00	0.938	23.83	38.124	968.34	391.68	583.05
40	1000	—	40.000	1016.00	1.000	25.40	38.000	965.20	416.91	620.48
40	1000	—	40.000	1016.00	1.062	26.97	37.876	962.06	442.06	657.78
40	1000	—	40.000	1016.00	1.125	28.58	37.750	958.84	467.52	695.92
40	1000	—	40.000	1016.00	1.188	30.18	37.624	955.64	492.90	733.68
40	1000	—	40.000	1016.00	1.250	31.75	37.500	952.50	517.80	770.62
42	1050	—	42.000	1067.00	0.344	8.74	41.312	1049.52	153.18	228.09
42	1050	STD	42.000	1067.00	0.375	9.53	41.250	1047.94	166.86	248.52
42	1050	—	42.000	1067.00	0.406	10.31	41.188	1046.38	180.52	268.66
42	1050	—	42.000	1067.00	0.438	11.13	41.124	1044.74	194.60	289.80
42	1050	—	42.000	1067.00	0.469	11.91	41.062	1043.18	208.22	309.88
42	1050	XS	42.000	1067.00	0.500	12.70	41.000	1041.60	221.82	330.19
42	1050	—	42.000	1067.00	0.562	14.27	40.876	1038.46	248.95	370.45
42	1050	—	42.000	1067.00	0.625	15.88	40.750	1035.24	276.44	411.62
42	1050	—	42.000	1067.00	0.688	17.48	40.624	1032.04	303.84	452.40
42	1050	—	42.000	1067.00	0.750	19.05	40.500	1028.90	330.72	492.30
42	1050	—	42.000	1067.00	0.812	20.62	40.376	1025.76	357.52	532.07
42	1050	—	42.000	1067.00	0.875	22.23	40.250	1022.54	384.67	572.73
42	1050	—	42.000	1067.00	0.938	23.83	40.124	1019.34	411.74	613.02
42	1050	—	42.000	1067.00	1.000	25.40	40.000	1016.20	438.29	652.42
42	1050	—	42.000	1067.00	1.062	26.97	39.876	1013.06	464.76	691.70
42	1050	—	42.000	1067.00	1.125	28.58	39.750	1009.84	491.57	731.86
42	1050	—	42.000	1067.00	1.188	30.18	39.624	1006.64	518.30	771.64
42	1050	—	42.000	1067.00	1.250	31.75	39.500	1003.50	544.52	810.55
44	1100	—	44.000	1118.00	0.344	8.74	43.312	1100.52	160.54	239.08
44	1100	STD	44.000	1118.00	0.375	9.53	43.250	1098.94	174.88	260.50
44	1100	—	44.000	1118.00	0.406	10.31	43.188	1097.38	189.20	281.62
44	1100	—	44.000	1118.00	0.438	11.13	43.124	1095.74	203.97	303.80
44	1100	—	44.000	1118.00	0.469	11.91	43.062	1094.18	218.25	324.86
44	1100	XS	44.000	1118.00	0.500	12.70	43.000	1092.60	232.51	346.16
44	1100	—	44.000	1118.00	0.562	14.27	42.876	1089.46	260.97	388.40
44	1100	—	44.000	1118.00	0.625	15.88	42.750	1086.24	289.80	431.59
44	1100	—	44.000	1118.00	0.688	17.48	42.624	1083.04	318.55	474.39
44	1100	—	44.000	1118.00	0.750	19.05	42.500	1079.90	346.76	516.26
44	1100	—	44.000	1118.00	0.812	20.62	42.376	1076.76	374.88	558.01
44	1100	—	44.000	1118.00	0.875	22.23	42.250	1073.54	403.38	600.69
44	1100	—	44.000	1118.00	0.938	23.83	42.124	1070.34	431.79	642.99
44	1100	—	44.000	1118.00	1.000	25.40	42.000	1067.20	459.67	684.37
44	1100	—	44.000	1118.00	1.062	26.97	41.876	1064.06	487.47	725.62
44	1100	—	44.000	1118.00	1.125	28.58	41.750	1060.84	515.63	767.80
44	1100	—	44.000	1118.00	1.188	30.18	41.624	1057.64	543.70	809.60
44	1100	—	44.000	1118.00	1.250	31.75	41.500	1054.50	571.25	850.49
46	1150	—	46.000	1168.00	0.344	8.74	45.312	1150.52	167.89	249.85
46	1150	STD	46.000	1168.00	0.375	9.53	45.250	1148.94	182.90	272.25
46	1150	—	46.000	1168.00	0.406	10.31	45.188	1147.38	197.88	294.34
46	1150	—	46.000	1168.00	0.438	11.13	45.124	1145.74	213.33	317.52
46	1150	—	46.000	1168.00	0.469	11.91	45.062	1144.18	228.28	339.54
46	1150	XS	46.000	1168.00	0.500	12.70	45.000	1142.60	243.20	361.82
46	1150	—	46.000	1168.00	0.562	14.27	44.876	1139.46	272.98	406.00
46	1150	—	46.000	1168.00	0.625	15.88	44.750	1136.24	303.16	451.17
46	1150	—	46.000	1168.00	0.688	17.48	44.624	1133.04	333.26	495.94
46	1150	—	46.000	1168.00	0.750	19.05	44.500	1129.90	362.79	539.75
46	1150	—	46.000	1168.00	0.812	20.62	44.376	1126.76	392.24	583.43
46	1150	—	46.000	1168.00	0.875	22.23	44.250	1123.54	422.09	628.10
46	1150	—	46.000	1168.00	0.938	23.83	44.124	1120.34	451.85	672.37
46	1150	—	46.000	1168.00	1.000	25.40	44.000	1117.20	481.05	715.68
46	1150	—	46.000	1168.00	1.062	26.97	43.876	1114.06	510.17	758.88
46	1150	—	46.000	1168.00	1.125	28.58	43.750	1110.84	539.68	803.04
46	1150	—	46.000	1168.00	1.188	30.18	43.624	1107.64	569.10	846.81
46	1150	—	46.000	1168.00	1.250	31.75	43.500	1104.50	597.97	889.63
48	1200	—	48.000	1219.00	0.344	8.74	47.312	1201.52	175.25	260.85
48	1200	STD	48.000	1219.00	0.375	9.53	47.250	1199.94	190.92	284.24
48	1200	—	48.000	1219.00	0.406	10.31	47.188	1198.38	206.56	307.30
48	1200	—	48.000	1219.00	0.438	11.13	47.124	1196.74	222.70	331.52
48	1200	—	48.000	1219.00	0.469	11.91	47.062	1195.18	238.30	354.52
48	1200	XS	48.000	1219.00	0.500	12.70	47.000	1193.60	253.89	377.79
48	1200	—	48.000	1219.00	0.562	14.27	46.876	1190.46	285.00	423.94
48	1200	—	48.000	1219.00	0.625	15.88	46.750	1187.24	316.52	471.14
48	1200	—	48.000	1219.00	0.688	17.48	46.624	1184.04	347.97	517.92
48	1200	—	48.000	1219.00	0.750	19.05	46.500	1180.90	378.83	563.70
48	1200	—	48.000	1219.00	0.812	20.62	46.376	1177.76	409.61	609.36
48	1200	—	48.000	1219.00	0.875	22.23	46.250	1174.54	440.80	656.06
48	1200	—	48.000	1219.00	0.938	23.83	46.124	1171.34	471.90	702.34
48	1200	—	48.000	1219.00	1.000	25.40	46.000	1168.20	502.43	747.63
48	1200	—	48.000	1219.00	1.062	26.97	45.876	1165.06	532.88	792.80
48	1200	—	48.000	1219.00	1.125	28.58	45.750	1161.84	563.73	838.99
48	1200	—	48.000	1219.00	1.188	30.18	45.624	1158.64	594.50	884.77
48	1200	—	48.000	1219.00	1.250	31.75	45.500	1155.50	624.70	929.56
52	1300	—	52.000	1321.00	0.375	9.53	51.250	1301.94	206.95	308.21
52	1300	—	52.000	1321.00	0.406	10.31	51.188	1300.38	223.93	333.24
52	1300	—	52.000	1321.00	0.438	11.13	51.124	1298.74	241.43	359.51
52	1300	—	52.000	1321.00	0.469	11.91	51.062	1297.18	258.36	384.48
52	1300	—	52.000	1321.00	0.500	12.70	51.000	1295.60	275.27	409.74
52	1300	—	52.000	1321.00	0.562	14.27	50.876	1292.46	309.03	459.84
52	1300	—	52.000	1321.00	0.625	15.88	50.750	1289.24	343.25	511.09
52	1300	—	52.000	1321.00	0.688	17.48	50.624	1286.04	377.38	561.89
52	1300	—	52.000	1321.00	0.750	19.05	50.500	1282.90	410.90	611.62
52	1300	—	52.000	1321.00	0.812	20.62	50.376	1279.76	444.33	661.23
52	1300	—	52.000	1321.00	0.875	22.23	50.250	1276.54	478.21	711.98
52	1300	—	52.000	1321.00	0.938	23.83	50.124	1273.34	512.01	762.28
52	1300	—	52.000	1321.00	1.000	25.40	50.000	1270.20	545.19	811.52
52	1300	—	52.000	1321.00	1.062	26.97	49.876	1267.06	578.29	860.63
52	1300	—	52.000	1321.00	1.125	28.58	49.750	1263.84	611.84	910.88
52	1300	—	52.000	1321.00	1.188	30.18	49.624	1260.64	645.30	960.68
52	1300	—	52.000	1321.00	1.250	31.75	49.500	1257.50	678.15	1009.42
56	1400	—	56.000	1422.00	0.375	9.53	55.250	1402.94	222.99	331.94
56	1400	—	56.000	1422.00	0.406	10.31	55.188	1401.38	241.29	358.92
56	1400	—	56.000	1422.00	0.438	11.13	55.124	1399.74	260.15	387.24
56	1400	—	56.000	1422.00	0.469	11.91	55.062	1398.18	278.41	414.14
56	1400	—	56.000	1422.00	0.500	12.70	55.000	1396.60	296.65	441.37
56	1400	—	56.000	1422.00	0.562	14.27	54.876	1393.46	333.06	495.38
56	1400	—	56.000	1422.00	0.625	15.88	54.750	1390.24	369.97	550.64
56	1400	—	56.000	1422.00	0.688	17.48	54.624	1387.04	406.80	605.43
56	1400	—	56.000	1422.00	0.750	19.05	54.500	1383.90	442.97	659.07
56	1400	—	56.000	1422.00	0.812	20.62	54.376	1380.76	479.05	712.59
56	1400	—	56.000	1422.00	0.875	22.23	54.250	1377.54	515.63	767.34
56	1400	—	56.000	1422.00	0.938	23.83	54.124	1374.34	552.12	821.63
56	1400	—	56.000	1422.00	1.000	25.40	54.000	1371.20	587.95	874.78
56	1400	—	56.000	1422.00	1.062	26.97	53.876	1368.06	623.70	927.81
56	1400	—	56.000	1422.00	1.125	28.58	53.750	1364.84	659.94	982.06
56	1400	—	56.000	1422.00	1.188	30.18	53.624	1361.64	696.10	1035.85
56	1400	—	56.000	1422.00	1.250	31.75	53.500	1358.50	731.60	1088.50
60	1500	—	60.000	1524.00	0.375	9.53	59.250	1504.94	239.02	355.92
60	1500	—	60.000	1524.00	0.406	10.31	59.188	1503.38	258.65	384.85
60	1500	—	60.000	1524.00	0.438	11.13	59.124	1501.74	278.88	415.23
60	1500	—	60.000	1524.00	0.469	11.91	59.062	1500.18	298.46	444.10
60	1500	—	60.000	1524.00	0.500	12.70	59.000	1498.60	318.03	473.31
60	1500	—	60.000	1524.00	0.562	14.27	58.876	1495.46	357.09	531.27
60	1500	—	60.000	1524.00	0.625	15.88	58.750	1492.24	396.70	590.58
60	1500	—	60.000	1524.00	0.688	17.48	58.624	1489.04	436.22	649.40
60	1500	—	60.000	1524.00	0.750	19.05	58.500	1485.90	475.04	706.99
60	1500	—	60.000	1524.00	0.812	20.62	58.376	1482.76	513.77	764.45
60	1500	—	60.000	1524.00	0.875	22.23	58.250	1479.54	553.04	823.26
60	1500	—	60.000	1524.00	0.938	23.83	58.124	1476.34	592.23	881.57
60	1500	—	60.000	1524.00	1.000	25.40	58.000	1473.20	630.71	938.67
60	1500	—	60.000	1524.00	1.062	26.97	57.876	1470.06	669.11	995.64
60	1500	—	60.000	1524.00	1.125	28.58	57.750	1466.84	708.04	1053.95
60	1500	—	60.000	1524.00	1.188	30.18	57.624	1463.64	746.90	1111.76
60	1500	—	60.000	1524.00	1.250	31.75	57.500	1460.50	785.05	1168.37
64	1600	—	64.000	1626.00	0.375	9.53	63.250	1606.94	255.06	379.89
64	1600	—	64.000	1626.00	0.406	10.31	63.188	1605.38	276.01	410.78
64	1600	—	64.000	1626.00	0.438	11.13	63.124	1603.74	297.61	443.23
64	1600	—	64.000	1626.00	0.469	11.91	63.062	1602.18	318.52	474.06
64	1600	—	64.000	1626.00	0.500	12.70	63.000	1600.60	339.41	505.26
64	1600	—	64.000	1626.00	0.562	14.27	62.876	1597.46	381.12	567.16
64	1600	—	64.000	1626.00	0.625	15.88	62.750	1594.24	423.42	630.52
64	1600	—	64.000	1626.00	0.688	17.48	62.624	1591.04	465.64	693.36
64	1600	—	64.000	1626.00	0.750	19.05	62.500	1587.90	507.11	754.90
64	1600	—	64.000	1626.00	0.812	20.62	62.376	1584.76	548.49	816.32
64	1600	—	64.000	1626.00	0.875	22.23	62.250	1581.54	590.46	879.17
64	1600	—	64.000	1626.00	0.938	23.83	62.124	1578.34	632.34	941.51
64	1600	—	64.000	1626.00	1.000	25.40	62.000	1575.20	673.47	1002.56
64	1600	—	64.000	1626.00	1.062	26.97	61.876	1572.06	714.52	1063.48
64	1600	—	64.000	1626.00	1.125	28.58	61.750	1568.84	756.15	1125.83
64	1600	—	64.000	1626.00	1.188	30.18	61.624	1565.64	797.70	1187.67
64	1600	—	64.000	1626.00	1.250	31.75	61.500	1562.50	838.50	1248.23
68	1700	—	68.000	1727.00	0.469	11.91	67.062	1703.18	338.57	503.72
68	1700	—	68.000	1727.00	0.500	12.70	67.000	1701.60	360.79	536.89
68	1700	—	68.000	1727.00	0.562	14.27	66.876	1698.46	405.15	602.71
68	1700	—	68.000	1727.00	0.625	15.88	66.750	1695.24	450.15	670.08
68	1700	—	68.000	1727.00	0.688	17.48	66.624	1692.04	495.06	736.90
68	1700	—	68.000	1727.00	0.750	19.05	66.500	1688.90	539.18	802.35
68	1700	—	68.000	1727.00	0.812	20.62	66.376	1685.76	583.21	867.68
68	1700	—	68.000	1727.00	0.875	22.23	66.250	1682.54	627.87	934.54
68	1700	—	68.000	1727.00	0.938	23.83	66.124	1679.34	672.45	1000.86
68	1700	—	68.000	1727.00	1.000	25.40	66.000	1676.20	716.23	1065.82
68	1700	—	68.000	1727.00	1.062	26.97	65.876	1673.06	759.93	1130.66
68	1700	—	68.000	1727.00	1.125	28.58	65.750	1669.84	804.25	1197.02
68	1700	—	68.000	1727.00	1.188	30.18	65.624	1666.64	848.49	1262.84
68	1700	—	68.000	1727.00	1.250	31.75	65.500	1663.50	891.95	1327.30
72	1800	—	72.000	1829.00	0.500	12.70	71.000	1803.60	382.17	568.83
72	1800	—	72.000	1829.00	0.562	14.27	70.876	1800.46	429.18	638.60
72	1800	—	72.000	1829.00	0.625	15.88	70.750	1797.24	476.87	710.02
72	1800	—	72.000	1829.00	0.688	17.48	70.624	1794.04	524.48	780.87
72	1800	—	72.000	1829.00	0.750	19.05	70.500	1790.90	571.25	850.27
72	1800	—	72.000	1829.00	0.812	20.62	70.376	1787.76	617.93	919.54
72	1800	—	72.000	1829.00	0.875	22.23	70.250	1784.54	665.28	990.46
72	1800	—	72.000	1829.00	0.938	23.83	70.124	1781.34	712.55	1060.80
72	1800	—	72.000	1829.00	1.000	25.40	70.000	1778.20	758.99	1129.71
72	1800	—	72.000	1829.00	1.062	26.97	69.876	1775.06	805.34	1198.49
72	1800	—	72.000	1829.00	1.125	28.58	69.750	1771.84	852.36	1268.90
72	1800	—	72.000	1829.00	1.188	30.18	69.624	1768.64	899.29	1338.75
72	1800	—	72.000	1829.00	1.250	31.75	69.500	1765.50	945.40	1407.17
76	1900	—	76.000	1930.00	0.500	12.70	75.000	1904.60	403.55	600.46
76	1900	—	76.000	1930.00	0.562	14.27	74.876	1901.46	453.21	674.14
76	1900	—	76.000	1930.00	0.625	15.88	74.750	1898.24	503.60	749.57
76	1900	—	76.000	1930.00	0.688	17.48	74.624	1895.04	553.90	824.40
76	1900	—	76.000	1930.00	0.750	19.05	74.500	1891.90	603.32	897.71
76	1900	—	76.000	1930.00	0.812	20.62	74.376	1888.76	652.65	970.90
76	1900	—	76.000	1930.00	0.875	22.23	74.250	1885.54	702.70	1045.82
76	1900	—	76.000	1930.00	0.938	23.83	74.124	1882.34	752.66	1120.16
76	1900	—	76.000	1930.00	1.000	25.40	74.000	1879.20	801.75	1192.97
76	1900	—	76.000	1930.00	1.062	26.97	73.876	1876.06	850.75	1265.67
76	1900	—	76.000	1930.00	1.125	28.58	73.750	1872.84	900.47	1340.09
76	1900	—	76.000	1930.00	1.188	30.18	73.624	1869.64	950.09	1413.92
76	1900	—	76.000	1930.00	1.250	31.75	73.500	1866.50	998.85	1486.24
80	2000	—	80.000	2032.00	0.562	14.27	78.876	2003.46	477.25	710.04
80	2000	—	80.000	2032.00	0.625	15.88	78.750	2000.24	530.32	789.51
80	2000	—	80.000	2032.00	0.688	17.48	78.624	1997.04	583.32	868.37
80	2000	—	80.000	2032.00	0.750	19.05	78.500	1993.90	635.39	945.63
80	2000	—	80.000	2032.00	0.812	20.62	78.376	1990.76	687.37	1022.76
80	2000	—	80.000	2032.00	0.875	22.23	78.250	1987.54	740.12	1101.74
80	2000	—	80.000	2032.00	0.938	23.83	78.124	1984.34	792.77	1180.10
80	2000	—	80.000	2032.00	1.000	25.40	78.000	1981.20	844.51	1256.86
80	2000	—	80.000	2032.00	1.062	26.97	77.876	1978.06	896.17	1333.51
80	2000	—	80.000	2032.00	1.125	28.58	77.750	1974.84	948.57	1411.98
80	2000	—	80.000	2032.00	1.188	30.18	77.624	1971.64	1000.89	1489.83
80	2000	—	80.000	2032.00	1.250	31.75	77.500	1968.50	1052.30	1566.11

Showing ASME B36.10M-2015. 766 of 772 rows verified against the standard itself; every figure is checked against the standard’s own mass formula. How this data was verified.

What have you got?

Schedule (wall)

Where are you?

2 inch pipeDN 50SCH 40 · STD

It measures, across the outside60.30mm2.375 inches

Wall: 3.91 mm
Bore: 52.48 mm
Weight: 5.44 kg/m
Weight: 3.66 lb/ft

✓ VERIFIED — ASME B36.10M-2015

Check this before you order

Outside diameter at DN 50 by standard
Standard	OD	vs ASME
GOST 15 countries	57.0 mm	−3.3
GB/T B 1 country	57.0 mm	−3.3
ISO 65 46 countries	60.3 mm	baseline
ASME 30 countries	60.3 mm	baseline
EN 10220 56 countries	60.3 mm	baseline
JIS 9 countries	60.5 mm	+0.2

3.5 mm apart — more than the ±1% diameter tolerance steel pipe is made to, so these do not fit each other’s fittings.

What the Outside Diameter of a Pipe Actually Is

The outside diameter of 2-inch pipe is 2.375 inches (60.3 mm). It is the one dimension that never changes for a given nominal size: every schedule of 2-inch pipe measures 60.3 mm across the outside, and only the wall thickness — and therefore the bore — differs.

That is why pipe is specified as a nominal size plus a schedule. The size fixes the outside; the schedule fixes the wall. If you have a pipe in your hand and want to identify it, measure the outside diameter and match it here — and if the number on the pipe confuses you, start with why nominal pipe size isn’t the diameter.

Pipe Schedules and What They Change

A schedule number is a wall thickness, not a diameter. Schedules run from 5 through 160, plus the older designations STD, XS and XXS. Not every schedule exists at every size — the standard is a sparse table, and only 292 of the 616 possible size-and-schedule combinations have ever been manufactured.

Every size against every schedule. Only 292 of 616 combinations have ever been manufactured.

Schedule 40 pipe dimensions are the most commonly specified.

Standard, Extra Strong and Double Extra Strong

STD, XS and XXS predate the schedule system and are frequently treated as synonyms for schedules 40, 80 and 160. They are not.

STD = SCH 40: only through NPS 10; above that STD is fixed at 0.375 in
XS = SCH 80: only through NPS 8; above that XS is fixed at 0.500 in

At NPS 24, schedule 40 is 0.688 in and STD is still 0.375 in — a difference of nearly two-fifths of an inch on the same nominal pipe.

Pipe Sizes by Material

Outside diameters are shared across more materials than most charts admit. PVC pipe sizes use exactly the same outside diameter series as steel, at every comparable size. Copper does not.

Why Copper Is the Exception

US copper tube to ASTM B88 is named one-eighth of an inch below its actual outside diameter. A “½-inch” copper tube measures 0.625 in across the outside, not 0.5 — see copper pipe sizes for the full series and for why the rule changes at the border. And a UK 15 mm tube to EN 1057 measures exactly 15.00 mm — a different tube that will not fit US fittings, despite both being called half-inch in the trade.

Pipe Weight per Foot and per Metre

Weight is computed, not copied. Every mass figure on this site comes from the formula the standards themselves publish:

W = (OD − t) × t × C

where C is 10.69 for pounds per foot with inches, or 0.02466 for kilograms per metre with millimetres, for carbon steel at 7.85 g/cm³. Ductile iron is a different material with a different constant — 0.0221482 — and using the steel value on iron overstates the mass by 11.3%.

The Same Pipe Size Is Not the Same Everywhere

Ask what 2½-inch pipe measures and you get a different answer depending on which standard the question is asked under.

Outside diameter at DN 65 by standard
Standard	OD (mm)
ASME B36.10M	73.0
EN 10220	76.1
JIS G3452	76.3
GOST 3262	75.5

Which pipe standard each country uses covers all 157 we have mapped, and which of them are verified, while pipe standards compared puts the registers themselves side by side and shows exactly where they part.

The American value is the outlier. ISO 4200, the international series most national standards descend from, places 76.1 mm in Series 1 — its preferred tier — and places 73.0 mm in Series 3, which the standard defines as sizes for special application, some of which “may be withdrawn in due course”.

DN 65 drawn to scale under each standard. The same size name buys a pipe 3.3 mm wider in Japan than in the United States.

Where These Numbers Come From

766 of 772 rows are verified against ASME B36.10M-2015 itself, parsed from the published standard rather than copied from another chart. Every row is then checked against the standard’s own mass formula, which catches transcription errors that reading does not.

That check found genuine mistakes in published sources, including two in a primary source and two incorrect outside diameters on a chart currently ranking on the first page of Google. How this data was verified, and what could not be.

Frequently Asked Questions

What is the outside diameter of 1/2-inch pipe?: 1/2-inch pipe measures 0.840 inches — 21.3 mm — across the outside, and that figure does not change with the schedule. The schedule sets the wall inside that fixed outside diameter, so the bore moves and the outside does not: schedule 40 is 0.109 in thick and leaves a 0.622 in bore, schedule 80 is 0.147 in and leaves 0.546 in. Dimensions from ASME B36.10M-2015.
What is the outside diameter of 3/4-inch pipe?: 3/4-inch pipe measures 1.050 inches — 26.7 mm — across the outside, and that figure does not change with the schedule. The schedule sets the wall inside that fixed outside diameter, so the bore moves and the outside does not: schedule 40 is 0.113 in thick and leaves a 0.824 in bore, schedule 80 is 0.154 in and leaves 0.742 in. Dimensions from ASME B36.10M-2015.
What is the outside diameter of 1-inch pipe?: 1-inch pipe measures 1.315 inches — 33.4 mm — across the outside, and that figure does not change with the schedule. The schedule sets the wall inside that fixed outside diameter, so the bore moves and the outside does not: schedule 40 is 0.133 in thick and leaves a 1.049 in bore, schedule 80 is 0.179 in and leaves 0.957 in. Dimensions from ASME B36.10M-2015.
What is the outside diameter of 1-1/2-inch pipe?: 1-1/2-inch pipe measures 1.900 inches — 48.3 mm — across the outside, and that figure does not change with the schedule. The schedule sets the wall inside that fixed outside diameter, so the bore moves and the outside does not: schedule 40 is 0.145 in thick and leaves a 1.610 in bore, schedule 80 is 0.200 in and leaves 1.500 in. Dimensions from ASME B36.10M-2015.
What is the outside diameter of 2-inch pipe?: 2-inch pipe measures 2.375 inches — 60.3 mm — across the outside, and that figure does not change with the schedule. The schedule sets the wall inside that fixed outside diameter, so the bore moves and the outside does not: schedule 40 is 0.154 in thick and leaves a 2.067 in bore, schedule 80 is 0.218 in and leaves 1.939 in. Dimensions from ASME B36.10M-2015.
What is the outside diameter of 3-inch pipe?: 3-inch pipe measures 3.500 inches — 88.9 mm — across the outside, and that figure does not change with the schedule. The schedule sets the wall inside that fixed outside diameter, so the bore moves and the outside does not: schedule 40 is 0.216 in thick and leaves a 3.068 in bore, schedule 80 is 0.300 in and leaves 2.900 in. Dimensions from ASME B36.10M-2015.
What is the outside diameter of 4-inch pipe?: 4-inch pipe measures 4.500 inches — 114.3 mm — across the outside, and that figure does not change with the schedule. The schedule sets the wall inside that fixed outside diameter, so the bore moves and the outside does not: schedule 40 is 0.237 in thick and leaves a 4.026 in bore, schedule 80 is 0.337 in and leaves 3.826 in. Dimensions from ASME B36.10M-2015.
What is the outside diameter of 6-inch pipe?: 6-inch pipe measures 6.625 inches — 168.3 mm — across the outside, and that figure does not change with the schedule. The schedule sets the wall inside that fixed outside diameter, so the bore moves and the outside does not: schedule 40 is 0.280 in thick and leaves a 6.065 in bore, schedule 80 is 0.432 in and leaves 5.761 in. Dimensions from ASME B36.10M-2015.
What is the outside diameter of 8-inch pipe?: 8-inch pipe measures 8.625 inches — 219.1 mm — across the outside, and that figure does not change with the schedule. The schedule sets the wall inside that fixed outside diameter, so the bore moves and the outside does not: schedule 40 is 0.322 in thick and leaves a 7.981 in bore, schedule 80 is 0.500 in and leaves 7.625 in. Dimensions from ASME B36.10M-2015.
What is the outside diameter of 10-inch pipe?: 10-inch pipe measures 10.750 inches — 273 mm — across the outside, and that figure does not change with the schedule. The schedule sets the wall inside that fixed outside diameter, so the bore moves and the outside does not: schedule 40 is 0.365 in thick and leaves a 10.020 in bore, schedule 80 is 0.594 in and leaves 9.562 in. Dimensions from ASME B36.10M-2015.
What is the outside diameter of 12-inch pipe?: 12-inch pipe measures 12.750 inches — 323.8 mm — across the outside, and that figure does not change with the schedule. The schedule sets the wall inside that fixed outside diameter, so the bore moves and the outside does not: schedule 40 is 0.406 in thick and leaves a 11.938 in bore, schedule 80 is 0.688 in and leaves 11.374 in. Dimensions from ASME B36.10M-2015.
Why isn't 2-inch pipe 2 inches?: Nominal pipe size is a trade designation, not a measurement. It originally approximated the bore of the pipe. Wall thicknesses changed over time, the outside diameter was standardised, and the name stayed. From NPS 14 upward the nominal size does equal the outside diameter in inches.
What does schedule mean on a pipe?: Schedule specifies wall thickness, not diameter. For any given nominal size, every schedule shares the same outside diameter; a higher schedule number means a thicker wall and therefore a smaller bore.
Is schedule 40 the same as STD?: Only through NPS 10. From NPS 12 upward they diverge: STD is fixed at 0.375 inches while schedule 40 keeps increasing. At NPS 24, schedule 40 is 0.688 inches and STD is still 0.375 inches.
What is the difference between NPS and DN?: They name the same physical pipe in different units. Above DN 100 the relationship is arithmetic — DN equals 25 times NPS. Below DN 100 it is an irregular lookup that no formula reproduces.
Does PVC use the same sizes as steel pipe?: PVC schedule 40 and 80 use exactly the same outside diameters as steel, across all 19 comparable sizes. The wall thicknesses are also the same numbers, but they mean different things: ASTM publishes a minimum wall for PVC, while ASME publishes a nominal wall for steel.
What are the standard pipe sizes?: Nominal pipe sizes run from NPS 1/8 to NPS 80 — 44 sizes in ASME B36.10M-2015 — and each one fixes an outside diameter that every schedule shares. The full series, with the schedule walls available at each size, is the chart on this page.
What are the standard tube sizes?: Tube has no nominal series: it is ordered by its exact outside diameter, so 'tube sizes' are simply the manufactured diameter range rather than a standard table. Pipe is the opposite — a nominal name over a fixed outside diameter — which is why a 2-inch pipe measures 2.375 inches across. This site covers pipe dimensions; tube sizing works to different standards entirely.

Country missing or unverified? Tell us what it uses

Only 16 of 157 countries here are verified against the actual standard. Everything that comes in is checked against the standard it names before anything on the site moves.

info@pipesizechart.com

Anything is useful, but a report carrying these four things can be checked in minutes rather than investigated for a week.

Where you are: The country, and the standard the pipe is made to if it is marked.
What it is sold as: The size the way the merchant writes it — 2 inch, 50 NB, DN 50.
What it measures: The outside diameter in millimetres. Wrap a tape round the pipe and divide by 3.1416 if you have no callipers.
How we can check it: Best is a photograph of the marking stamped along the pipe, or of the dimension table in the standard itself. A mill test certificate or a manufacturer’s datasheet works too. With nothing attached it is kept as a lead rather than published.

Corrections to figures already published go to the same address and are treated the same way: tested against the standard’s own arithmetic, then published with a date. Nothing is edited silently.

PipeSize Chart
